VI-IR610

Name：VI-IR610 UHF RFID Industrial reader

• The shape is industrial design, very rugged and durable. It suit for Harsh industrial production line environment(includes Electromagnetic interference, dust, waterproof, anti demolition, maximum resistance -25 degrees -70 degrees environment, vibration, noise ),Waterproof IP67.
• Seismic standard Vibration EN 60 068-2-6;  Lightning protection standard: Shock EN 60 068-2-27; Magnetic compatibility (EMC:EN 61000-6-3(2007)+A1(2011)/EN61000-6-2(2005)
• RF uses self-development chip, coupled with a high performance label recognition algorithm
• standard interface RS232, RS485; optional access gateway adapter: Industrial Ethernet, ProfiNet
• Software intelligent monitoring of the working state, 24 hours X running for 365 days does not crash.
• Products through the authority of the domestic and international testing institutions certification FCC, CE, no certification, etc.
• The bottom cover is designed and installed to facilitate the installation of the industrial production line.
• It’s ideal equipment selection for industrial production line.

Product features

1. Fully support the tags of EPC global Class 1 Gen / 2 ISO 18000-6C standard;

2.  Frequency range 860-868MHZ, 902-928MHZ (can be customized);

3. Support RS232, RS485; optional access gateway adapter: achieve industrial Ethernet, ProfiNet

4. RF output power can be adjusted; the distance can be set among 30cm-200cm;

5.  Support active mode, command mode, triggers mode, etc.

6.  Read card beep and LED status indication; support for online upgrade of firmware via communication interface
